GIS Substation Estimation and Costing Course (Including One Bay Detailed Estimation)
If you’ve ever looked at a GIS substation drawing and felt confused about where to start the estimation, this course is designed exactly for that situation.
GIS substations are not like regular projects. Everything is compact, equipment-heavy, and cost-sensitive. One small mistake in estimation can lead to a major variation in project cost. That’s why this program focuses on building a strong, practical understanding rather than just theory.
In this course, you will start from the basics. You will first understand how a GIS substation is arranged, how to read layouts, and how to interpret single line diagrams in a simple way. Once that clarity is built, the course gradually moves into quantity takeoff for civil works like foundations, trenches, and buildings, along with structural supports and electrical components.
The real strength of this course is the detailed breakdown of one complete GIS bay. Instead of keeping things general, you will go step by step into one bay and understand every component inside it. You will learn how to identify equipment, calculate quantities, and then convert those quantities into proper costing.
You will also learn how actual project costing works. This includes understanding equipment pricing, installation charges, cable and earthing costs, and how everything is combined into a proper BOQ. The approach is practical and based on real project thinking, not classroom theory.
By the end of the course, you will be able to read GIS substation drawings with confidence, perform quantity takeoff, prepare BOQ, and develop a complete cost estimate for a bay as well as the overall substation.
This course is useful for civil engineers, electrical engineers, quantity surveyors, and anyone involved in substation projects who wants to move from basic knowledge to real working capability.
In simple words, this is not just about learning estimation. It is about learning how to actually do the job.
MODULE 1: Introduction to GIS Substation Estimation
- What is a GIS (Gas Insulated Substation)
- Difference between AIS and GIS from a costing point of view
- Why GIS is used in urban and high-voltage applications
- Overview of estimation stages in substation projects
- Key cost components: civil, electrical, mechanical, and installation
MODULE 2: Understanding GIS Substation Layout
- Typical GIS substation layout (indoor and outdoor interface)
- Major zones: GIS hall, control room, cable trenches, transformer yard
- Reading single line diagrams (SLD)
- Understanding bay configuration
- Interconnection between bays and systems
MODULE 3: Drawings Required for Estimation
- General arrangement drawings
- Foundation drawings
- Cable routing drawings
- Earthing layout
- Equipment layout drawings
- How to extract quantities from drawings
MODULE 4: Components of GIS Substation
- Circuit breakers
- Disconnectors and earthing switches
- Current transformers (CT)
- Voltage transformers (VT)
- Busbars and enclosures
- SF6 gas system overview
- Auxiliary systems
MODULE 5: Civil Works Estimation
- Excavation for foundations
- RCC foundations for GIS equipment
- Control building estimation
- Cable trenches and covers
- Road works and drainage
- Quantity takeoff methods
MODULE 6: Structural Works and Supports
- Steel structures for equipment support
- Gantry structures and bus supports
- Estimation of structural steel weight
- Fabrication and erection costs
- Anchor bolts and base plates
MODULE 7: Electrical Equipment Costing
- GIS equipment cost components
- Vendor-based costing approach
- Cost of breakers, CT, VT, isolators
- Transformer costing basics
- Protection and control panels
MODULE 8: Cable and Wiring Estimation
- Control cables and power cables
- Cable tray estimation
- Cable trench filling
- Termination and jointing
- Quantity calculation based on routing
MODULE 9: Earthing System Estimation
- Earthing grid layout
- Earth electrodes and conductors
- GI strip and copper conductor calculation
- Connections and welding points
- Earthing resistance considerations
MODULE 10: Auxiliary Systems Costing
- Fire fighting system
- Lighting system
- HVAC system for GIS hall
- Battery and charger systems
- DG backup system
MODULE 11: GIS Bay – Concept and Components
- What is a bay in GIS
- Types of bays (feeder, transformer, bus coupler)
- Components inside one bay
- Functional understanding of each equipment
- Interconnection within bay
MODULE 12: Detailed Quantity Takeoff of One GIS Bay
- Identification of all components in one bay
- Equipment count (breaker, CT, VT, isolators)
- Bus duct length calculation
- Support structures and foundation quantities
- Cable and earthing quantities
MODULE 13: Detailed Costing of One GIS Bay Equipment
- Breaker cost estimation
- CT and VT costing
- Disconnector costing
- GIS enclosure and bus system cost
- SF6 gas cost calculation
- Vendor quotation analysis
MODULE 14: Civil Costing for One GIS Bay
- Foundation concrete volume calculation
- Reinforcement estimation
- Formwork estimation
- Excavation and backfilling
- Finishing and grouting
MODULE 15: Structural Costing for One Bay
- Steel structure weight calculation
- Fabrication rate analysis
- Erection cost
- Bolting and welding cost
- Painting and protection
MODULE 16: Cable and Earthing Costing for One Bay
- Control cable quantity and cost
- Power cable estimation
- Cable tray cost
- Earthing conductor cost
- Installation and termination cost
MODULE 17: Installation and Erection Costing
- Equipment installation cost
- Testing and commissioning charges
- Labor productivity norms
- Machinery and lifting equipment cost
- Safety and supervision cost
MODULE 18: Complete BOQ Preparation for GIS Substation
- BOQ structure for GIS projects
- Item description writing
- Units and measurement standards
- Integration of civil + electrical BOQ
- Sample BOQ for one full bay
MODULE 19: Rate Analysis and Final Costing
- Material + labor + overhead calculation
- Profit margin and contingencies
- Escalation considerations
- Taxes and duties
- Final project costing sheet preparation
MODULE 20: Case Study – Full GIS Substation with One Bay Detailed Costing
- Real project scenario explanation
- Step-by-step costing of one complete bay
- Summary of total substation cost
- Cost comparison with AIS substation
- Common mistakes in estimation and how to avoid them
